Nidec US Motors U20P1GC 3-Phase C-Face Motor, 20 HP, 3-Phase, 3600 RPM, 575V, 256TC Frame

NidecSKU: C2095421
MPN : U20P1GC
Weight : 15.0 lb
filler

Price:
$2,295.09 $2,798.89

Availability : Usually Ships in 3-5 Business Days
  • Features: 40 degree C ambient, Suitable for Wye-Delta start

Item: General Purpose AC Motor, Motor Type: 3-Phase, HP: 20, Nameplate RPM: 3600, Voltage: 575, Frame: 256TC, Enclosure: Totally Enclosed, Rotation: CW/CCW, Hz: 60, Phase: 3, Speeds: 1, Service Factor: 1.25, Insulation Class: F, Mounting: Unimount, Bearings: Ball, Base: Rigid, Shaft Type: Key, Shaft Number: 1, Shaft Length: 4.25", Shaft Height: 6.25", Shaft Dia.: 1.625", "C" Dim: 25.8, Thermal Protection: No, Cooling: Fan Cooled, Efficiency: 91.

ItemGeneral Purpose AC Motor
Motor Type3-Phase
HP20
Nameplate RPM3600
Voltage575
Frame256TC
EnclosureTotally Enclosed
RotationCW/CCW
Hz60
Phase3
Speeds1
Service Factor1.25
Insulation ClassF
MountingUnimount
BearingsBall
BaseRigid
Shaft TypeKey
Shaft Number1
Shaft Length4.25"
Shaft Height6.25"
Shaft Dia.1.625"
"C" Dim25.8
Thermal ProtectionNo
CoolingFan Cooled
Efficiency91
