The Bobrick B-6806x30 Concealed Mounting With Snap Flange Grab Bar is a featured style from the 6806 Series of Bobrick commercial restroom accessories. Measuring 24 inches in length by 1-1/2 inches in diameter, the grab bar is crafted from 18-gauge stainless steel. To minimize the appearance of fingerprints but still offer an attractive shine, the stainless steel has a satin finish. In order to keep the installation screws out of sight and unit resistant to tampering, the grab bar features a 22-gauge stainless steel cover that is 3-1/4 inches in diameter and designed to snap onto the mounting flange. The flange measures 2 inches in width by 3-1/8 inches in height . The flange is 1/8 inches thick and is passed through by the grab bar, which is welded in place to make a one-piece unit. The grab bar has a maximum weight capacity of 900 pounds when installed with a 1-1/2 inch clearance space. 6806 Series, Stainless Steel, Stain Finish, Concealed Mounting with Snap Flange Grab Bars, 30", StraightÂ
| Product Type | Grab Bar |
| Material | Stainless Steel |
| Nominal Size (In.) | 30" X 1.5" |
| Surface Type | Smooth |
| Length (In.) | 30" |
| Dia. (In.) | 1.5" |
| Total Recycled Content | 65% |
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
