Availability : Usually Ships in 10 Business Days
Instant reverse motor feature electronic reversing with no moving parts required. Designed for mechanical doors, gates, hoists, and other equipment requiring remote control instant reversibility.
Item | Instant Reverse Motor |
Motor Application | Garage/Gate Opener |
Motor Design | Capacitor-Start |
Motor Enclosure Design | Open Dripproof |
HP | 1/3 |
Nameplate RPM | 1725 |
Frame | 56 |
Voltage | 115 |
Full Load Amps | 6.3 |
Phase | 1 |
Hz | 60 |
Motor Mounting Type | Rigid Base |
Motor Mounting Position | All Angle |
Motor Bearings | Ball |
Motor Thermal Protection | Manual |
Motor Service Factor | 1.35 |
Ambient Temperature | 40 Degrees C |
Motor Shaft Design | Keyed |
Shaft Dia. | 5/8 in |
Shaft Length | 1 7/8 in |
Ins. Class | B |
Number of Wires | 5 |
Application | For Mechanical Doors, Gates and Hoists |
Standards | CSA Certified, UL Recognized, and CE Certified |
RPM Range | 1701-1800 |
Voltage Compatibility | 115, 120 |
