Y Strainer; Pipe Size: 1/4 in; Connection Type: FNPT x FNPT; Housing Material: Cast Carbon Steel; Max. Pressure: 1010 psi @ 750 Degrees F WSP, 1480 psi @ 100 Degrees F WOG; Length: 2 15/16 in; Screen Material: 304 Stainless Steel; Mesh: 1/16 in; Gasket Material: Spiral Wound Graphite Filled; Max. Fluid Temp.: 100 Degrees F; Blow-off Port: 1/4 in; Class: 600
| Item | Y Strainer |
| Pipe Size | 1/4 in |
| Connection Type | FNPT x FNPT |
| Housing Material | Cast Carbon Steel |
| Max. Pressure | 1010 psi @ 750 Degrees F WSP, 1480 psi @ 100 Degrees F WOG |
| Length | 2 15/16 in |
| Screen Material | 304 Stainless Steel |
| Mesh | 1/16 in |
| Gasket Material | Spiral Wound Graphite Filled |
| Max. Fluid Temp. | 100 Degrees F |
| Blow-off Port | 1/4 in |
| Class | 600 |
