American Standard Exposed, Top Spud, Manual Flush Valve, For Use With Category Toilets, 1.1 Gallons per Flush - 6047111.002

American StandardSKU: C1936198
MPN : 6047111.002
Weight : 5.8 lb

filler

Price:
$178.84 $288.44

Availability : Usually Ships in 7 Business Days

Manual toilet flush valves are sized to fit tankless toilets. These hand-activated valves have a spud coupling for attaching to a toilet spud. They typically require a high-pressure water supply to operate.,Manual flush valves are hand-activated valves for flushing tankless toilets and urinals. Also known as manual flushometers, these flow-control devices are a cost-effective alternative to automatic valves and have a lever or button that requires no power source to operate.

ItemManual Flush Valve
Flush Valve LocationExposed
Fixture ConnectionTop Spud
Brand and SeriesAmerican Standard
For Use With CategoryToilets
Flush ModeSingle Flush
Gallons per Flush1.1
Flush Valve DesignPiston
Rough-In11 1/2 in
Spud Coupling1 1/2 in
Inlet Size1 in IPS
Pressure Range25 to 80 psi
FinishChrome Plated
IncludesCover Tube, Sweat Solder Kit, Wall Flange
Manufacturers Warranty Length5 yr
StandardsADA, ANSI/ASME 112.192, ASSE 1037
Green Environmental AttributeToilet Uses 1.28 gpf or Less
