Apollo Ball Valve, Bronze, Inline, 2-Piece, Pipe Size 2 in, Connection Type FNPT x FNPT - 701082741

Apollo ValvesSKU: C2673060
MPN : 701082741
Weight : 5.65 lb

filler

Price:
$218.25 $352.02

Availability : Usually Ships in 25 Business Days

Bronze Ball Valves with Auto Drain, Max. pressure: 600 psi WOG, 150 psi WSP,Standard-port valves have 2-pc. B584 bronze body with B16 brass retainer and RPTFE reinforced seats. Blowoutproof stem design with adjustable packing gland and automatic drain. Handle is zinc-plated steel. FNPT connections.,Meet MSS SP-110 standards.

ItemBall Valve
Body MaterialBronze
Body StyleInline
General Connection TypeFemale NPT
Valve Structure2-Piece
Pipe Size2 in
Connection TypeFNPT x FNPT
PortStandard
Max. Pressure125 psi CWP
Temp. Range-20 Degrees to 450 Degrees F
Ball MaterialChrome Plated Brass
Seat MaterialRPTFE
Stem TypeBlowout Proof
Handle TypeLocking Lever
Handle MaterialZinc Plated Steel with Vinyl Grip
Stem Material316 Stainless Steel
Body Seal MaterialPTFE
FeaturesSS Latch-Lock Lever with Auto Drain
Ball Valve Product GroupManual
Valve Basic Body MaterialBronze
StandardsMSS SP-110
Overall Length10.24 in
