Apollo Check Valve, 3/4 in, Single, Inline Ball Cone, Bronze, Press x Press - 61LF10401PR

Apollo ValvesSKU: C1910642
MPN : 61LF10401PR
Weight : 1.0 lb

filler

Price:
$85.99 $138.69

Availability : Usually Ships in 25 Business Days

Low-Lead Bronze Ball Cone Check Valves, Max. pressure: 250 psi Max. temp.: 250F,Ideal for direct mechanical connection to ASTM B88 Type K, L, and M hard drawn copper tubing. PTFE seats and 316 stainless steel springs. Press connection. Valves are not for use with reciprocating pumps and similar applications. Not suitable for flammable gas or steam service. Can be mounted vertically or horizontally.,Meet NSF/ANSI 61-8 (2010) Annex F and G, NSF-372, and MSS-SP139.

Item - Check ValvesCheck Valve
Flow DesignSingle
Mechanism and Body DesignInline Ball Cone
Body Material - ValvesBronze
Pipe or Tube Size - Check Valves3/4 in
Connection Type - Check ValvesPress x Press
Cracking Pressure - Check Valves0.5 psi
Mounting Orientation - Check ValvesHorizontal, Vertical
Seal Material - Check ValvesEPDM
Max. Temp. - Valves180 Degrees F
Min. Temp. - Valves33 Degrees F
Max. Water Pressure - Valves250 psi
Max. Steam Pressure - Valves15 psi WSP
Seat Material - Check ValvesRPTFE
Spring Material - Check Valves316 Stainless Steel
Flow - Valves3.5 gpm
Application - ValvesGeneral Purpose
Length5 in
Width5 in
StandardsNSF 372, NSF61-G
