Apollo Globe Valve, FNPT x FNPT, 316 Stainless Steel, 3/8 in Pipe Size - Valves - 60B70201
filler
Availability : Usually Ships in 15 Business Days
This 316 stainless steel globe valve features molybdenum-alloyed construction, which offers high resistance to pitting corrosion. It features a hand wheel and threaded stem that causes a disc-shaped plug inside the valve to open or shut off the flow of air, fluid, or gas. FNPT thread connection. Has PTFE stem packing.
| Item - Globe Valves | Globe Valve |
| Pipe Size - Valves | 3/8 in |
| Connection Type - Valves | FNPT x FNPT |
| Shape - Globe Valves | Tee |
| Body Material - Valves | 316 Stainless Steel |
| Media - Valves | Air, Fluid, Gas |
| Valve Stem Design | Rising |
| Valve Handle Design | Cross |
| Max. Fluid Temp. - Valves | 100 Degrees F |
| Max. Air Pressure | 10,000 psig @ 100 Degrees F |
| Max. Fluid Pressure - Valves | 10,000 psi |
| Max. Steam Pressure - Valves | Not Rated |
| Inlet to Outlet Length - Valves | 2 1/4 in |
| Top of Handle to Inlet Center - Valves | 3 13/32 in |
| Max. Air Temp. | -50 Degrees to 550 Degrees F |
| Stem Material | Stainless Steel |
| Bonnet Style | Hub |
| Wedge Material | 316 Stainless Steel |
| Seal Material | PTFE |
| Handle Material | Malleable Iron |
| Standards | MSS SP-99, NACE MR0175(ED 2000)&MR0103(2012), SP-105 |
| Item | Globe Valve |
