Apollo Bronze Safety Relief Valve, FNPT Inlet Type, FNPT Outlet Type - 1060525

Apollo ValvesSKU: C1931800
MPN : 1060525
Weight : 4.25 lb
filler

Price:
$193.28 $235.71

Availability : Usually Ships in 1-3 Business Days

ASME Section IV Safety Relief Valves, Pressure range: 15 to 160 psig Max. temp.: 250F,Protect against excessive water pressure due to failure of controls to regulate BTU input. High BTU capacity rating. Corrosion-resistant with silicone seat. Fabric reinforced, molded diaphragm isolates spring from water at all times. FNPT connections. Designed for boilers, heating systems, and unfired pressure vessels.,Meet ASME Section IV Coded for hot water; HV National Board Certified and CRN.

ItemSafety Relief Valve
Body MaterialBronze
Inlet TypeFNPT
Outlet TypeFNPT
Inlet Size1 in
Outlet Size1 in
Factory Set Pressure125 psi
Pressure Range15 to 160 psi
BtuH4,272,000
Disc MaterialBrass ASTM B16
Overall Height6 11/16 in
ApplicationHot Water Heating Boilers and Hot Water Supply Systems
Overall Length4 in
Seat MaterialSilicone
Spring MaterialPlated Alloy Steel
Temp. Range0 Degrees to 250 Degrees F
Test LeverYes
StandardsASME Section IV, CRN, CSA
