Armstrong 12 gpm Cast Iron Condensate Cooler - CC-12

Armstrong InternationalSKU: C1952375
MPN : CC-12
Weight : 80.0 lb
filler

Price:
$3,351.84 $4,087.61

Availability : Usually Ships in 10-15 Business Days

Use to mix hot water or hot condensate with a cold water supply to help reduce the temperature to an acceptable level. Can cool to a preset temperature, or field set to a desired temperature. Suitable for most plumbing systems.

ItemCondensate Cooler
Capacity12 gpm
Body MaterialCast Iron
Preset Temp.135 Degrees F
Temp. Range115 Degrees to 180 Degrees F
Condensate Inlet1 1/2 in
Cold Water Inlet3/4 in
Condensate Outlet1 1/2 in
Vent Outlet1 1/2 in
Max. Pressure150 psig
Sensing Bulb MaterialBronze
Fittings MaterialMalleable Iron
Overall Height23 in
Overall Width14 3/16 in
Overall Depth11 in
