ASCO 24VDC Brass Solenoid Valve, Normally Closed, 1/8" Pipe Size - SC8256B045V

ASCOSKU: C1935506
MPN : SC8256B045V
Weight : 1.0 lb


$68.57 $83.62

Availability : Usually Ships in 7-10 Business Days
ItemSolenoid Valve
Solenoid Valve Product GroupSolenoid Valve
Valve Ways and Positions2-Way/2-Position
Valve ConfigurationNormally Closed
Media - ValvesAir, Inert Gases, Light Oil, Water
Pipe Size - Valves1/8 in
Min. Operating Pressure Differential0 psi
Max. Operating Pressure Differential Air/Inert Gas25 psi
Max. Operating Pressure Differential Light Oil25 psi
Max. Operating Pressure Differential Water25 psi
Environmental Rating - ValvesIndoor, Outdoor
Voltage24V DC
Coefficient of Volume0.19
Body Material - ValvesBrass
Coil Insulation ClassF
Seal Material - ValvesFKM
Orifice Dia.7/64 in
NEMA Rating4, 4X
IP Rating66
Max. Fluid Temp.180 Degrees F
Watts6.9 W
Coil EnclosureWatertight No Junction Box
Electrical ConnectionsDIN
Overall Length1 9/16 in
Overall Width1 in
Overall Height2 1/4 in
Center Line Pipe Center Size2 in
