Bradley S19-220BF Wall Mount Eyewash Station

BradleySKU: C1975042
MPN : S19-220BF
Weight : 19.0 lb

filler

Price:
$1,024.25 $1,478.00

Availability : Usually Ships in 4 Business Days
  • Stainless Steel Bowl
  • Hand Activation
  • Barrier Free/ADA
  • Eye/Facewash Sprayhead
  • Wall Mount
  • 1/2" NPT Supply Inlet
  • 1 1/4" Waste Outlet
  • Exceeds 3.0 GPM at 30 PSI
  • Meets ANSI Z358.1

The Bradley S19-220BF is a wall-mounted eyewash unit that exceeds the American National Standards Institute's Z358.1 performance requirements, as certified by Underwriters Laboratory Inc. The unit is crafted from galvanized steel covered with BradTect safety yellow coating and outfitted with a universal identification sign to make it highly visible for quick access when emergencies occur. The drench shower is backed by a one-year warranty from the manufacturer and also includes an inspection tag. Designed to offer a steady flow of water from pressures of 30 PSI to 90 PSI, the eyewash bowl measures 10 inches in diameter and is outfitted with chrome-plated brass sprayheads. This model includes a ½-inch NPT stay-open chrome-plated ball valve which is activated by pulling on a safety yellow PVC handle. The wall bracket is fabricated from heavy cast aluminum and has three holes for easy mounting with hardware that must be purchased separately. The unit complies fully with ADA barrier-free accessibility guidelines.


From the Manufacturer:

Safety Eye/Facewash. Barrier-Free Design. Wall Mounting. Stainless Steel Bowl with Wrap Around Skirt. Chrome Plated Brass Pipe & Fittings for Bright, Mirror Finish. Hand Activated. 1/2" NPT Water Supply . 1" Drain Fitting, Tailpiece and Trap Furnished for Eye or Eye/Face Wash. Chrome Plated Brass Eyewash. Universal Identification Sign and Inspection Tag Included. Complies with ANSI Standard Z358.1 When Installed and Used Properly. Manufacturer's Limited Warranty.
ItemBarrier Free Eyewash
Sprayhead Eyewash
Mounting Wall Mount
Eyewash Bowl Material Stainless Steel
