Century AO Smith ARB2024M Split-Phase Resilient Motor, 1/4 HP, Split-Phase, 1725 RPM, 115V, 56Z Frame

CenturySKU: c2090445
MPN : ARB2024M
Weight : 15.0 lb
filler

Price:
$343.03 $418.33

Availability : Usually Ships in 3-5 Business Days
  • Features: Extended thru-bolts shaft end

Item: Direct Drive Blower Motor, Motor Type: Split-Phaselit Phase, HP: 1/4, Nameplate RPM: 1725, Voltage: 115, Frame: 56Z, Enclosure: Totally Enclosed, Rotation: CW/CCW, Hz: 60, Phase: 1, Speeds: 1, Service Factor: 1, Insulation Class: B, Bearings: Sleeve, Base: Resilient, Shaft Type: Flat, Shaft Number: 1, Shaft Length: 1.625", Shaft Height: 3.5", Shaft Dia.: 0.5", "C" Dim: 10.1, Protection: Manual, Thermal Protection: Yes, Cooling: Ambient.

ItemDirect Drive Blower Motor
Motor TypeSplit-Phaselit Phase
HP1/4
Nameplate RPM1725
Voltage115
Frame56Z
EnclosureTotally Enclosed
RotationCW/CCW
Hz60
Phase1
Speeds1
Service Factor1
Insulation ClassB
BearingsSleeve
BaseResilient
Shaft TypeFlat
Shaft Number1
Shaft Length1.625"
Shaft Height3.5"
Shaft Dia.0.5"
"C" Dim10.1
ProtectionManual
Thermal ProtectionYes
CoolingAmbient
