Century AO Smith BN61 Split-Phase Motor, 2, 1/4 HP, PSC, 3450, 1725 RPM, 230V, 48Y Frame

CenturySKU: c2090508
MPN : BN61
Weight : 15.0 lb
filler

Price:
$388.97 $474.35

Availability : Usually Ships in 3-5 Business Days
  • Features: 40 degree C ambient, 48/56 Base mounting, Energy efficient, capacitor mounted on motor shell

Item: Pool and Spa Pump Motor, Motor Type: PSC, HP: 2, 1/4, Nameplate RPM: 3450, 1725, Voltage: 230, Frame: 48Y, Enclosure: Drip Proof, Rotation: CCW, Hz: 60, Phase: 1, Speeds: 2, Service Factor: 1, Insulation Class: B, Bearings: Ball, Base: Rigid, Shaft Type: Threaded, Shaft Number: 1, Shaft Length: 1.625", Shaft Height: 3.5", Shaft Dia.: 0.5", "C" Dim: 13.33, Protection: Auto, Thermal Protection: Yes, Cooling: Ambient.

ItemPool and Spa Pump Motor
Motor TypePSC
HP2, 1/4
Nameplate RPM3450, 1725
Voltage230
Frame48Y
EnclosureDrip Proof
RotationCCW
Hz60
Phase1
Speeds2
Service Factor1
Insulation ClassB
BearingsBall
BaseRigid
Shaft TypeThreaded
Shaft Number1
Shaft Length1.625"
Shaft Height3.5"
Shaft Dia.0.5"
"C" Dim13.33
ProtectionAuto
Thermal ProtectionYes
CoolingAmbient
