- Cross Reference: Carbonator
- Features: Carbonator pump
Item: Carbonator Pump Motor, Motor Type: Split-Phaselit Phase, HP: 1/3, Nameplate RPM: 1725, Voltage: 115, Frame: 48Y, Enclosure: Totally Enclosed, Rotation: CW, Hz: 60, Phase: 1, Speeds: 1, Service Factor: 1, Insulation Class: B, Bearings: Sleeve, Base: Resilient, Shaft Type: Special, Shaft Number: 1, Shaft Height: 3", "C" Dim: 8.6, Protection: Auto, Thermal Protection: Yes, Cooling: Ambient.
| Item | Carbonator Pump Motor |
| Motor Type | Split-Phaselit Phase |
| HP | 1/3 |
| Nameplate RPM | 1725 |
| Voltage | 115 |
| Frame | 48Y |
| Enclosure | Totally Enclosed |
| Rotation | CW |
| Hz | 60 |
| Phase | 1 |
| Speeds | 1 |
| Service Factor | 1 |
| Insulation Class | B |
| Bearings | Sleeve |
| Base | Resilient |
| Shaft Type | Special |
| Shaft Number | 1 |
| Shaft Height | 3" |
| "C" Dim | 8.6 |
| Protection | Auto |
| Thermal Protection | Yes |
| Cooling | Ambient |
