Designed for use with pumps, industrial fans, blowers, and exhaust fans.
| Item | Belt Drive Motor |
| Motor Application | HVAC/R |
| Motor Sub Application | Belt Drive Fan/Blower |
| Motor Design | 3-Phase |
| HP | 1-1/2 to 11/16 |
| No. of Speeds | 2 |
| Nameplate RPM | 1745/1140 |
| Voltage | 200-230 |
| Frame | 56H |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Cradle Base |
| Motor Mounting Position | All Angle |
| Hz | 60 |
| Full Load Amps | 4.8-4.6/2.8-2.7 |
| Motor Thermal Protection | None |
| Ins. Class | B |
| Motor Service Factor | 1.15 |
| Motor Bearings | Ball |
| Motor Frame Material | Steel |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Shaft Rotation | CW/CCW |
| Shaft Dia. | 5/8 in |
| Shaft Length | 1 5/8 in |
| Length Less Shaft | 10 13/16 in |
| Overall Length | 12 7/16 in |
| Body Dia. | 6 1/2 in |
| Mounting Stud Pattern | 4-1/8 in x 4-1/8 in |
| Resilient Ring Dia. | 2 1/2 in |
| Ring to Ring Center | 10 5/16 in |
| Nominal Efficiency | 74 % |
| Duty | Continuous |
| Phase | 3 |
| Standards | CSA Certified (4642), UL Recognized (E44549) |
| Voltage Compatibility | 200, 200-230, 200-230/440, 200-230/460, 208, 208-230, 208-240 |
