Item: Direct Drive Blower Motor, Motor Type: Split-Phaselit Phase, HP: 1/3, Nameplate RPM: 1725, Voltage: 115, Frame: 48, Enclosure: Open, Rotation: CW/CCW, Hz: 60, Phase: 1, Speeds: 1, Service Factor: 1.15, Insulation Class: B, Bearings: Sleeve, Base: Resilient, Shaft Type: Flat, Shaft Number: 1, Shaft Length: 1.625", Shaft Height: 3", Shaft Dia.: 0.5", "C" Dim: 9.4, Protection: None, Thermal Protection: No, Cooling: Ambient.
| Item | Direct Drive Blower Motor |
| Motor Type | Split-Phaselit Phase |
| HP | 1/3 |
| Nameplate RPM | 1725 |
| Voltage | 115 |
| Frame | 48 |
| Enclosure | Open |
| Rotation | CW/CCW |
| Hz | 60 |
| Phase | 1 |
| Speeds | 1 |
| Service Factor | 1.15 |
| Insulation Class | B |
| Bearings | Sleeve |
| Base | Resilient |
| Shaft Type | Flat |
| Shaft Number | 1 |
| Shaft Length | 1.625" |
| Shaft Height | 3" |
| Shaft Dia. | 0.5" |
| "C" Dim | 9.4 |
| Protection | None |
| Thermal Protection | No |
| Cooling | Ambient |
