Century AO Smith RS2034L Split-Phase Resilient Motor, 1/3 HP, Split-Phase, 1725 RPM, 115V, 48 Frame

CenturySKU: c2090456
MPN : RS2034L
Weight : 15.0 lb
filler

Price:
$263.63 $321.50

Availability : Usually Ships in 3-5 Business Days

Item: Direct Drive Blower Motor, Motor Type: Split-Phaselit Phase, HP: 1/3, Nameplate RPM: 1725, Voltage: 115, Frame: 48, Enclosure: Open, Rotation: CW/CCW, Hz: 60, Phase: 1, Speeds: 1, Service Factor: 1.15, Insulation Class: B, Bearings: Sleeve, Base: Resilient, Shaft Type: Flat, Shaft Number: 1, Shaft Length: 1.625", Shaft Height: 3", Shaft Dia.: 0.5", "C" Dim: 9.4, Protection: None, Thermal Protection: No, Cooling: Ambient.

ItemDirect Drive Blower Motor
Motor TypeSplit-Phaselit Phase
HP1/3
Nameplate RPM1725
Voltage115
Frame48
EnclosureOpen
RotationCW/CCW
Hz60
Phase1
Speeds1
Service Factor1.15
Insulation ClassB
BearingsSleeve
BaseResilient
Shaft TypeFlat
Shaft Number1
Shaft Length1.625"
Shaft Height3"
Shaft Dia.0.5"
"C" Dim9.4
ProtectionNone
Thermal ProtectionNo
CoolingAmbient
