Century AO Smith TCF81007E 3-Phase C-Face Motor, 10 HP, 3500 RPM, 230, 460V, 215TC Frame

CenturySKU: c2091614
MPN : TCF81007E
Weight : 15.0 lb

filler

Price:
$1,327.21 $1,618.55

Availability : Usually Ships in 3-5 Business Days
  • Features: 40 degree C ambient

Item: General Purpose AC Motor, Motor Type: 3-Phase, HP: 10, Nameplate RPM: 3500, Voltage: 230/460, Frame: 215TC, Enclosure: Totally Enclosed, Rotation: CW/CCW, Hz: 60, Phase: 3, Speeds: 1, Service Factor: 1.15, Insulation Class: F, Bearings: Ball, Base: Rigid, Shaft Type: Key, Shaft Number: 1, Shaft Length: 2.75", Shaft Height: 5.25", Shaft Dia.: 1.375", "C" Dim: 19.4, Protection: None, Thermal Protection: No, Cooling: Fan Cooled.

ItemGeneral Purpose AC Motor
Motor Type3-Phase
HP10
Nameplate RPM3500
Voltage230/460
Frame215TC
EnclosureTotally Enclosed
RotationCW/CCW
Hz60
Phase3
Speeds1
Service Factor1.15
Insulation ClassF
BearingsBall
BaseRigid
Shaft TypeKey
Shaft Number1
Shaft Length2.75"
Shaft Height5.25"
Shaft Dia.1.375"
"C" Dim19.4
ProtectionNone
Thermal ProtectionNo
CoolingFan Cooled
