Dayton 1/2 HP, General Purpose Motor, 3-Phase, 1725 Nameplate RPM, 230/460 Voltage, 56 Frame - 31TT08

DaytonSKU: C2979641
MPN : 31TT08
Weight : 29.15 lb

filler

Price:
$657.91 $1,061.15

Availability : Usually Ships in 3 Business Days

Motor complies with 2015 efficiency legislation for small-frame motors.

ItemGeneral Purpose Motor
Motor ApplicationGeneral Application
Motor Design3-Phase
Motor Enclosure DesignOpen Dripproof
HP1/2
Nameplate RPM1725
Frame56
Voltage230/460
Hz60/50
Phase3
Full Load Amps1.7/0.85
No. of Speeds1
Motor Mounting TypeRigid Base
Motor Mounting PositionAll Angle
Motor Thermal ProtectionNone
Ins. ClassB
Motor Service Factor1.25
Motor BearingsBall
Motor Frame MaterialRolled Steel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.5/8 in
Shaft Length1 7/8 in
Length Less Shaft9 1/8 in
Overall Length11 1/8 in
Motor Shaft DesignKeyed
StandardsUL Recognized for US and Canada (E47479)
DutyContinuous
Motor Efficiency GroupPremium Efficient
Nominal Efficiency78.2 %
Inverter RatedYes
IncludesShaft Slinger
Manufacturers Warranty Length1 yr
Green Environmental AttributeProduct Contributes To Reducing Energy Consumption
Green Certification or Other RecognitionEnergy Aware Certified
