Dayton 1/3 HP, General Purpose Motor, 3-Phase, 1140 Nameplate RPM, 230/460 Voltage, 56 Frame - 31TT10

DaytonSKU: C2979794
MPN : 31TT10
Weight : 25.6 lb

filler

Price:
$388.68 $474.00

Availability : Usually Ships in 3-5 Business Days

Motor complies with 2015 efficiency legislation for small-frame motors.

ItemGeneral Purpose Motor
Motor ApplicationGeneral Application
Motor Design3-Phase
Motor Enclosure DesignOpen Dripproof
HP1/3
Nameplate RPM1140
Frame56
Voltage230/460
Hz60/50
Phase3
Full Load Amps1.4/0.7
No. of Speeds1
Motor Mounting TypeRigid Base
Motor Mounting PositionHorizontal
Motor Thermal ProtectionNone
Ins. ClassB
Motor Service Factor1.35
Motor BearingsBall
Motor Frame MaterialRolled Steel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.5/8 in
Shaft Length1 7/8 in
Length Less Shaft10 in
Overall Length12 in
Motor Shaft DesignKeyed
StandardsUL Recognized for US and Canada (E47479)
DutyContinuous
Motor Efficiency GroupPremium Efficient
Nominal Efficiency71.4 %
Inverter RatedYes
Manufacturers Warranty Length1 yr
Green Environmental AttributeProduct Contributes To Reducing Energy Consumption
Green Certification or Other RecognitionEnergy Aware Certified
