Use with applications that protect the motor's electrical components, fan system, and housing. For applications such as hopper loaders, commercial vacuums, and material handling and transfer systems. Should not come into contact with foam, liquids, or moisture-laden air.
| Item | Vacuum Motor |
| Motor/Blower Type | Bypass |
| Discharge | Peripheral Bypass |
| Blower Stages | 2 |
| No. of Speeds | 1 |
| Inlet Tube Dia. | 2 in |
| Motor Enclosure Design | Open |
| CFM @ 2-In. Orifice | 105 |
| Vacuum (H2O Sealed) | 95 |
| Voltage | 120 |
| Hz | 60 |
| Phase | 1 |
| Max. Amps | 11 A |
| Max. Air Watts | 320 W |
| Motor Mounting Type | Lug |
| Motor Design | Universal AC/DC |
| Motor Mounting Position | All Angle |
| Motor Thermal Protection | Auto |
| Ins. Class | B |
| Bearings | Ball |
| Ambient Temperature | 40 Degrees C |
| Body Dia. | 5.7 in |
| Overall Height | 7 in |
| Mounting Brackets | Metal |
| Duty | Intermittent |
| Average Life | 500 hr |
| Motor Efficiency Group | Standard Efficient |
| Standards | UL Recognized for US and Canada (E47479) |
| Replacement Brushes | 34DA21 |
