Dayton 1/3 HP 50 Hz Motor,Split-Phase,1425 Nameplate RPM,110/220 Voltage,Frame 56Z - 6XH81BA

DaytonSKU: C1567245
MPN : 6XH81BA
Weight : 17.0 lb

filler

Price:
$350.85 $565.88

Availability : Usually Ships in 10 Business Days

1-phase motor features start switch and windings designed for reliable operation in 50 Hz applications. Use this motor machinery, air compressors, conveyors, fans, blowers, machine tools, speed reducers, pumps, and industrial equipment in noncombustible environments.

Item50 Hz Motor
Motor ApplicationGeneral Application
Motor DesignSplit-Phase
Motor Enclosure DesignOpen Dripproof
HP1/3
No. of Speeds1
Nameplate RPM1425
Voltage110/220
Hz50
Phase1
Full Load Amps6.1/3
Frame56Z
Motor Mounting TypeCradle Base
Motor Mounting PositionAll Angle
Motor Thermal ProtectionAuto
Ins. ClassB
Motor Service Factor1
Motor BearingsBall
Motor Shaft RotationCW/CCW
Motor Shaft DesignFlat
Ambient Temperature40 Degrees C
Shaft Dia.1/2 in
Shaft Length1 1/2 in
Length Less Shaft7 7/8 in
Overall Length9 3/8 in
RPM Range1401-1500
Voltage Compatibility110/220 50 Hz, 220 50 Hz
