Dayton AC/DC Gearmotor 115VAC/DC Nameplate RPM 24 RPM Enclosure Open Vented - 1LRA1

DaytonSKU: C1661103
MPN : 1LRA1
Weight : 6.8 lb

filler

Price:
$359.96 $580.58

Availability : Usually Ships in 12-15 Business Days

Universal 115VAC/DC Right-Angle Gearmotors,Enclosure: vented Gearcase: die-cast zinc Lubrication: grease-filled Gears: input gear steel; output gear cast iron Bearings: bronze sleeve on case and motor Mounting: all-position 60/50 Hz Rotation: reversible Thermal protection: none Brushes: replaceable; approx. 300 hr. life Ambient: 40C Overall depth 8-7/8" Input power: 1/15 HP UL Recognized,Note: Ratings shown are at 60 Hz. Gearmotors are also operable at 50 Hz, with HP and rpm at 5/6 of the 60-Hz rating.

ItemAC/DC Gearmotor
Gearmotor TypeAC/DC Gearmotor
Gearmotor Voltage115V AC/DC
Full Load Torque85 in-lb
Gearmotor Shaft TypeDouble
Gearmotor Shaft OrientationRight Angle
Nameplate RPM24 RPM
Insulation ClassB
Gearmotor Mounting PositionAll Angle
Length Less Shaft8 3/4 in
Hz60/50 Hz
Gearmotor Phase1
Reversible Shaft OutputNo
Overhung Load100 lb
Input HP1/15
Gear Ratio1
Full Load Amps1.3 A
Gearmotor EnclosureOpen
Thermal ProtectionNone
Max. Ambient Temp.40 Degrees C
Gearmotor RotationCW/CCW
Motor TypeUniversal
Overall Length8 9/16 in
Keyway Size Type#404 Woodruff Key
Shaft Dia. (Dimension U)1/2 in
Shaft Length (Dimension V)1 5/8 in
BearingsPorous Bronze Sleeve on Case, Sleeve on Motor
LubricationGrease Filled
BrushesExternally Replaceable
FinishUnpainted
Housing MaterialDie Cast Zinc
Gear CaseDie Cast Zinc
Gear MaterialInput Gear Steel, Worm Hardened Steel, Output Gear Cast Iron
Gear TypeWorm
SealsLip Type on Output Shaft
StandardsUL Recognized
Replacement Brushes1YNR3
