Dayton DC Gearmotor 12VDC, Nameplate RPM: 39, Max. Torque: 26.0 in.-lb., Enclosure: TENV - 1LPV4

DaytonSKU: C1661072
MPN : 1LPV4
Weight : 4.72 lb

filler

Price:
$255.81 $412.60

Availability : Usually Ships in 12-15 Business Days

12VDC Permanent-Magnet Parallel-Shaft Gearmotors,Enclosure: totally enclosed nonventilated Gearcase: die-cast zinc Lubrication: grease-filled Gears: heat-treated steel and acetal Bearings: porous bronze sleeve on case; ball on motor Mounting: all-position Rotation: reversible Thermal protection: none Brushes: externally replaceable Ambient: 40C Seals: O-ring type on output shaft UL and C-UL Recognized

ItemDC Gearmotor
Gearmotor TypeDC Gearmotor
Gearmotor Voltage12 V DC
Max. Torque26 in.-lb.
Gearmotor Shaft TypeSingle
Gearmotor Shaft OrientationParallel
Rear Shaft Encoder/Pulse Generator MountingNo
Nameplate RPM39
Gearmotor EnclosureTotally Enclosed Nonventilated
Gearmotor Mounting PositionAll Angle
Length Less Shaft5-5/8"
Reversible Shaft OutputNo
Overhung Load50 lb.
Input HP1/30
Gear Ratio1
Full Load Amps2.1
Insulation ClassF
Thermal ProtectionNone
Max. Ambient Temp.40 Degrees C
Gearmotor RotationCW/CCW
Motor TypePermanent Magnet DC
Overall Length6-3/8"
Keyway Size TypeFlat
Shaft Dia. (Dimension U)5/16"
Shaft Length (Dimension V)3/4"
BearingsPorous Bronze Sleeve on Case, Ball on Motor
LubricationGrease Filled
BrushesExternally Replaceable
FinishUnpainted
Gear MaterialAcetyl/Steel
Gear CaseDie Cast Zinc
SealsO-Ring Type on Output Shaft
Housing MaterialDie Cast Zinc
StandardsC-UL Recognized, UL Recognized
Replacement Brushes6YHY4
