DC Gearmotor; Gearmotor Type: DC Gearmotor; Gearmotor Voltage: 90V DC; Max. Torque: 500 in-lb; Gearmotor Shaft Type: Single; Gearmotor Shaft Orientation: Parallel; Rear Shaft Encoder/Pulse Generator Mounting: No; Nameplate RPM: 6 RPM; Gearmotor Enclosure: Totally Enclosed Nonventilated; Gearmotor Mounting Position: All Angle; Length Less Shaft: 8 7/8 in; Reversible Shaft Output: No; Overhung Load: 300 lb; Input HP: 1/11; Gear Ratio: 264:1; Full Load Amps: 1.1 A; Insulation Class: F; Thermal Protection: None; Max. Ambient Temp.: 40 Degrees C; Gearmotor Rotation: CW/CCW; Motor Type: Permanent Magnet DC; Overall Length: 10 1/4 in; Keyway Size Type: 9/50 sq in x 1 in; Shaft Dia. (Dimension U): 3/4 in; Shaft Length (Dimension V): 1 3/8 in; Bearings: Ball and Needle on Case, Ball on Motor; Lubrication: Grease Filled; Brushes: Externally Replaceable; Finish: Unpainted; Gear Material: Hardened Steel; Gear Type: Helical and Spur; Gear Case: Die Cast Aluminum; Seals: Lip Type on Input and Output Shaft; Housing Material: Die Cast Aluminum; Standards: C-UL Recognized, UL Recognized; Replacement Brushes: 6YHY6
| Item | DC Gearmotor |
| Gearmotor Type | DC Gearmotor |
| Gearmotor Voltage | 90V DC |
| Max. Torque | 500 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Rear Shaft Encoder/Pulse Generator Mounting | No |
| Nameplate RPM | 6 RPM |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Mounting Position | All Angle |
| Length Less Shaft | 8 7/8 in |
| Reversible Shaft Output | No |
| Overhung Load | 300 lb |
| Input HP | 1/11 |
| Gear Ratio | 1 |
| Full Load Amps | 1.1 A |
| Insulation Class | F |
| Thermal Protection | None |
| Max. Ambient Temp. | 40 Degrees C |
| Gearmotor Rotation | CW/CCW |
| Motor Type | Permanent Magnet DC |
| Overall Length | 10 1/4 in |
| Keyway Size Type | 9/50 sq in x 1 in |
| Shaft Dia. (Dimension U) | 3/4 in |
| Shaft Length (Dimension V) | 1 3/8 in |
| Bearings | Ball and Needle on Case, Ball on Motor |
| Lubrication | Grease Filled |
| Brushes | Externally Replaceable |
| Finish | Unpainted |
| Gear Material | Hardened Steel |
| Gear Type | Helical and Spur |
| Gear Case | Die Cast Aluminum |
| Seals | Lip Type on Input and Output Shaft |
| Housing Material | Die Cast Aluminum |
| Standards | C-UL Recognized, UL Recognized |
