DC Gearmotor; Gearmotor Type: DC Gearmotor; Gearmotor Voltage: 90V DC; Max. Torque: 500 in-lb; Gearmotor Shaft Type: Single; Gearmotor Shaft Orientation: Parallel; Rear Shaft Encoder/Pulse Generator Mounting: No; Nameplate RPM: 6.5 RPM; Gearmotor Enclosure: Totally Enclosed Nonventilated; Gearmotor Mounting Position: All Angle; Length Less Shaft: 8 1/2 in; Reversible Shaft Output: No; Overhung Load: 250 lb; Input HP: 1/15; Gear Ratio: 267:1; Full Load Amps: 0.84 A; Insulation Class: F; Thermal Protection: None; Max. Ambient Temp.: 40 Degrees C; Gearmotor Rotation: CW/CCW; Motor Type: Permanent Magnet DC; Overall Length: 10 in; Keyway Size Type: #605 Woodruff Key; Shaft Dia. (Dimension U): 3/4 in; Shaft Length (Dimension V): 1 1/2 in; Bearings: Porous Bronze Sleeve on Case, Ball on Motor; Lubrication: Grease Filled; Brushes: Externally Replaceable; Finish: Unpainted; Gear Material: Hardened Steel/Phenolic; Gear Case: Die Cast Zinc; Seals: O-Ring Type on Output Shaft; Housing Material: Die Cast Zinc; Standards: C-UL Recognized, UL Recognized; Replacement Brushes: 6YHY6
| Item | DC Gearmotor |
| Gearmotor Type | DC Gearmotor |
| Gearmotor Voltage | 90V DC |
| Max. Torque | 500 in-lb |
| Gearmotor Shaft Type | Single |
| Gearmotor Shaft Orientation | Parallel |
| Rear Shaft Encoder/Pulse Generator Mounting | No |
| Nameplate RPM | 6.5 RPM |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Mounting Position | All Angle |
| Length Less Shaft | 8 1/2 in |
| Reversible Shaft Output | No |
| Overhung Load | 250 lb |
| Input HP | 1/15 |
| Gear Ratio | 1 |
| Full Load Amps | 0.84 A |
| Insulation Class | F |
| Thermal Protection | None |
| Max. Ambient Temp. | 40 Degrees C |
| Gearmotor Rotation | CW/CCW |
| Motor Type | Permanent Magnet DC |
| Overall Length | 10 in |
| Keyway Size Type | #605 Woodruff Key |
| Shaft Dia. (Dimension U) | 3/4 in |
| Shaft Length (Dimension V) | 1 1/2 in |
| Bearings | Porous Bronze Sleeve on Case, Ball on Motor |
| Lubrication | Grease Filled |
| Brushes | Externally Replaceable |
| Finish | Unpainted |
| Gear Material | Hardened Steel/Phenolic |
| Gear Case | Die Cast Zinc |
| Seals | O-Ring Type on Output Shaft |
| Housing Material | Die Cast Zinc |
| Standards | C-UL Recognized, UL Recognized |
| Replacement Brushes | 6YHY6 |
