Dayton 1/2 HP, General Purpose Motor, Capacitor-Start/Run, 1725 Nameplate RPM, 115/208-230 Voltage - 103876

DaytonSKU: C1547795
MPN : 103876
Weight : 20.1 lb

filler

Price:
$457.75 $738.30

Availability : Usually Ships in 3 Business Days

Motor complies with 2015 efficiency legislation for small-frame motors.

ItemGeneral Purpose Motor
Motor ApplicationGeneral Application
Motor DesignCapacitor-Start/Run
Motor Enclosure DesignOpen Dripproof
HP1/2
Nameplate RPM1725
Frame56C
Voltage115/208-230
Hz60
Phase1
Full Load Amps4.6/2.4-2.3
No. of Speeds1
Motor Mounting TypeFace
Motor Mounting PositionHorizontal or Vertical Shaft Down
Motor Thermal ProtectionAuto
Ins. ClassB
Motor Service Factor1.25
Motor BearingsBall
Motor Frame MaterialRolled Steel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.5/8 in
Shaft Length1 7/8 in
Length Less Shaft9 3/8 in
Overall Length11 7/16 in
Motor Shaft DesignKeyed
StandardsUL Recognized for US and Canada (E37403)
DutyContinuous
Motor Efficiency GroupPremium Efficient
Nominal Efficiency76.2 %
Inverter RatedNo
Includes110V AC, Run Capacitor, Start Capacitor 540 to 648 MFD
Manufacturers Warranty Length1 yr
Green Environmental AttributeProduct Contributes To Reducing Energy Consumption
Green Certification or Other RecognitionEnergy Aware Certi
