Dayton 1/2 HP, General Purpose Motor, Capacitor-Start/Run, 3450 Nameplate RPM, 115/208-230 Voltage - 103814

DaytonSKU: C1547750
MPN : 103814
Weight : 17.4 lb

filler

Price:
$435.11 $701.80

Availability : Usually Ships in 3 Business Days

Motor complies with 2015 efficiency legislation for small-frame motors. 40C max. ambient temperature.

ItemGeneral Purpose Motor
Motor ApplicationGeneral Application
Motor DesignCapacitor-Start/Run
Motor Enclosure DesignOpen Dripproof
HP1/2
Nameplate RPM3450
Frame48
Voltage115/208-230
Hz60
Phase1
Full Load Amps4.4/2.4-2.2
No. of Speeds1
Motor Mounting TypeRigid Base
Motor Mounting PositionHorizontal or Vertical Shaft Down
Motor Thermal ProtectionManual
Ins. ClassB
Motor Service Factor1.25
Motor BearingsBall
Motor Frame MaterialSteel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.1/2 in
Shaft Length1 1/2 in
Length Less Shaft9 in
Overall Length10 5/8 in
Motor Shaft DesignFlat
StandardsUL (E37403)
DutyContinuous
Motor Efficiency GroupPremium Efficient
Nominal Efficiency72.4 %
Inverter RatedNo
Includes297 MFD Capacitor(440 MFD, 125V Start Capacitor & 30 MFD, 370V Run Capacitor)
Manufacturers Warranty Length1 yr
Green Environmental AttributeProduct Contributes To Reducing Energy Consumption
Green Certification or Other RecognitionEnergy Aware Certified
