Dayton 1 HP, General Purpose Motor, 3-Phase, 1725 Nameplate RPM, 230/460 Voltage, 56 Frame - 31TT12

DaytonSKU: C1554562
MPN : 31TT12
Weight : 34.95 lb

filler

Price:
$664.47 $1,071.72

Availability : Usually Ships in 3 Business Days

Motor complies with 2015 efficiency legislation for small-frame motors.

ItemGeneral Purpose Motor
Motor ApplicationGeneral Application
Motor Design3-Phase
Motor Enclosure DesignOpen Dripproof
HP1
Nameplate RPM1725
Frame56
Voltage230/460
Hz60/50
Phase3
Full Load Amps3/1.5
No. of Speeds1
Motor Mounting TypeRigid Base
Motor Mounting PositionAll Angle
Motor Thermal ProtectionNone
Ins. ClassB
Motor Service Factor1.15
Motor BearingsBall
Motor Frame MaterialRolled Steel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.5/8 in
Shaft Length1 7/8 in
Length Less Shaft9 3/4 in
Overall Length11 11/16 in
Motor Shaft DesignKeyed
StandardsUL Recognized for US and Canada (E47479)
DutyContinuous
Motor Efficiency GroupPremium Efficient
Nominal Efficiency83.5 %
Inverter RatedYes
Manufacturers Warranty Length1 yr
Green Environmental AttributeProduct Contributes To Reducing Energy Consumption
Green Certification or Other RecognitionEnergy Aware Certified
