Dayton 1/4 HP Belt Drive Motor, Capacitor-Start, 1725 Nameplate RPM, 115/208-230 Voltage, Frame 48YZ - 1AGG1

DaytonSKU: C1544506
MPN : 1AGG1
Weight : 14.8 lb
filler

Price:
$300.25 $366.16

Availability : Usually Ships in 3-5 Business Days

Permanent split capacitor motor includes capacitor; designed specifically as replacement motors for Dayton ventilators.

ItemBelt Drive Motor
Motor ApplicationHVAC/R
Motor Sub ApplicationBelt Drive Fan/Blower
Motor DesignCapacitor-Start
HP1/4
No. of Speeds1
Nameplate RPM1725
Voltage115/208-230
Frame48YZ
Motor Enclosure DesignOpen Dripproof
Motor Mounting TypeCradle Base
Motor Mounting PositionAll Angle
Hz60
Full Load Amps6.2/2.8-3.1
Motor Thermal ProtectionAuto
Ins. ClassB
Motor Service Factor1.35
Motor BearingsBall
Motor Frame MaterialRolled Steel
Max. Ambient Temp.40 Degrees C
Motor Shaft RotationCW/CCW
Shaft Dia.1/2 in
Shaft Length1 7/8 in
Length Less Shaft7 13/16 in
Overall Length9 11/16 in
Body Dia.5 5/8 in
Mounting Stud Pattern3-5/8 in x 3-5/8 in
Resilient Ring Dia.2 1/4 in
Ring to Ring Center7 3/8 in
DutyContinuous
Phase1
StandardsCSA Certified, UL Recognized
Voltage Compatibility115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240
