Dayton 1/2 HP Power Tool Motor,Capacitor-Start,3450 Nameplate RPM,115/230 Voltage,Frame 56 - 4K141BB

DaytonSKU: C1560654
MPN : 4K141BB
Weight : 21.9 lb

filler

Price:
$369.09 $450.11

Availability : Usually Ships in 3-5 Business Days

Dual-shaft power tool motor is designed for use in high-speed, moderate-starting-torque woodworking and metalworking tools; wood lathes, sanders, grinders, table saws, planers, and other applications where maximum HP load will not exceed nameplate rating.

ItemPower Tool Motor
Motor ApplicationPower Tool
Motor DesignCapacitor-Start
Motor Enclosure DesignOpen Dripproof
HP1/2
Nameplate RPM3450
Frame56
Voltage115/230
Hz60
Phase1
Full Load Amps6.8/3.4
Motor Mounting TypeRigid Base
Motor Thermal ProtectionManual
Ins. ClassA
Motor Service Factor1
Motor BearingsBall
Ambient Temperature40 Degrees C
Motor Shaft RotationCW/CCW
Length Less Shaft8 5/8 in
Shaft Dia.5/8 in
Shaft Length(2) 1 7/8 in
StandardsUL Component Recognized (E47479) and CSA Certified (701887)
RPM Range3001-3600
Voltage Compatibility115, 115/230, 120, 120/240, 230, 240
