Dayton Variable Frequency Drive,3 hp Max. HP,3 Input Phase AC,480V AC Input Voltage - 13E641

DaytonSKU: C1541954
MPN : 13E641
Weight : 12.1 lb

filler

Price:
$755.08 $1,217.86

Availability : Usually Ships in 5 Business Days

This adjustable frequency drive provides overload protection, prevents motor burnout, and eliminates nuisance tripping. It's housed in a heavy-duty NEMA 4X die-cast aluminum washdown/watertight enclosure, for indoor or outdoor use. It combines the digital technology of the microprocessor with an easy-to-use analog interface. Simple trimpot adjustments and selectable jumpers are used in lieu of complicated programming.

ItemVariable Frequency Drive
Max. HP3 hp
EnclosureNEMA 4X
Input Voltage480V AC
Max. Output Amps4.6 A
Output Voltage480V AC
Input Phase AC3
Output Phase AC3
With Bypass / No BypassNo Bypass
With Line Contactor / No Line ContactorNo Line Contactor
Starting Torque200%
Torque @ 1 Hz100 %
Input Frequency50/60 Hz
Output Frequency Range0 to 60/120 Hz
Adjustable Acceleration Time0.3 to 20 sec
Adjustable Deceleration Time0.3 to 20 sec
Dynamic BrakingInjection Braking
Height9.8 in
Width7.55 in
Depth7.25 in
Control TypeJumpers, Trimpots and Analog Display
Key Pad LockoutNo
Start/Stop ControlStart/Stop Switch Std
ProtectionElectronic Inrush Current Limit (EICL), Ride Through, Regeneration Protection, Overload, Current Limit, Short Circuit, Overvoltage, Under voltage, Nuisance Tripping, Phase loss, MOV Input Transient Suppression
Control MethodSensor less Flux Vector with Static Auto Tune with Boost, Volts per Hertz
Accepts Input Control SignalWith Signal Isolator Option
Display TypeLED
