The Guardian G1902P is a combination eyewash and shower safety station that features two GS-Plus spray heads, a 10" diameter orange ABS plastic shower head, an 11-3/4" ABS plastic eyewash bowl, and galvanized steel pipe and fittings. The eyewash and shower valves are chrome plated brass stay-open ball valves made in the U.S. The unit is furnished with an ANSI compliant identification sign, and both the valve and spray head assemblies are tested prior to shipping.
Includes:
Flip Top Dust Covers, High Visibility Identification Sign, Orange Covers For Vertical Piping And Inspection Tag
Application: Combination eyewash and shower safety station. Eyewash features a plastic bowl with two GS-Plus™ spray-type outlet heads that deliver a flood of water for rinsing eyes.
Shower Head: 10" diameter orange ABS plastic with 20 GPM flow control.
Shower Valve: 1" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals. Furnished with stainless steel actuating arm and 29" stainless steel pull rod.
Spray Head Assembly: Two GS-Plus™ spray heads. Each head has a “flip top” dust cover, internal flow control and filter to remove impurities from water flow.
Eyewash Bowl: 11-3/4" diameter orange ABS plastic.
Eyewash Valve: 1/2" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals.
Pipe and Fittings: Schedule 40 galvanized steel. Furnished with orange polyethylene pipe covers for high visibility and corrosion resistance.
Supply: 1-1/4" NPT female top or side inlet.
Waste: 1-1/4" NPT female outlet. Outlet can be positioned at either 9-1/4" or 19-5/8" above finished floor by reversing lower pipe nipples.
Sign: ANSI-compliant identification sign.
Quality Assurance: Valve and spray head assemblies are factory assembled and water tested prior to shipment.
| Item | Shower with Eye Wash |
| Pipe Material | Galvanized Steel |
| Eye Wash Bowl Material | ABS Plastic |
| Shower Head Material | Plastic |
| Valve Material | Brass |
| Color | Orange |
| Width | 16 in |
| Height | 96 in |
| Head Dia. | 1 1/2 in |
| Bowl Dia. | 11 3/4 in |
| Eye Wash Activates By | Flag Push Handle |
| Eye Wash Handle Material | Cast Aluminum |
| Shower Head Activates By | Pull Handle |
| Shower Handle Length | 30 in |
| Shower Handle Material | Stainless Steel |
| Fitting Size | 1-1/4 in |
| Fitting Material | Galvanized Steel |
| Eye Wash and Shower Mounting | Floor |
| Standards | ANSI Z358.1-2014 |
| ADA Compliance | No |
| Assembled/Unassembled | Unassembled |
| Eye Wash Covering | Yes |
| ANSI Compliant | Yes |
| Heat Traced | No |
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
