Availability : Usually Ships in 3-5 Business Days
Item - Check Valves: Check Valve; Flow Design: Single; Mechanism and Body Design: Inline Swing; Body Material - Valves: Brass; Pipe or Tube Size - Check Valves: 2 in; Connection Type - Check Valves: FNPT x FNPT; Cracking Pressure - Check Valves: 0.75 to 1 psi; Mounting Orientation - Check Valves: Horizontal, Vertical; Seal Material - Check Valves: Brass; Min. Temp. - Valves: -20 Degrees F; Max. Water Pressure - Valves: 200 psi @ 150 Degrees F; Max. Steam Pressure - Valves: Not Rated; Seat Material - Check Valves: Brass; Flow - Valves: 131 gpm; Full Flow - Valves: Yes; Application - Valves: General Purpose; Length: 6 1/8 in; Cap to Inlet Center: 2 11/16 in; Standards: ASTM B584
Item - Check Valves | Check Valve |
Flow Design | Single |
Mechanism and Body Design | Inline Swing |
Body Material - Valves | Brass |
Pipe or Tube Size - Check Valves | 2 in |
Connection Type - Check Valves | FNPT x FNPT |
Cracking Pressure - Check Valves | 0.75 to 1 psi |
Mounting Orientation - Check Valves | Horizontal, Vertical |
Seal Material - Check Valves | Brass |
Min. Temp. - Valves | -20 Degrees F |
Max. Water Pressure - Valves | 200 psi @ 150 Degrees F |
Max. Steam Pressure - Valves | Not Rated |
Seat Material - Check Valves | Brass |
Flow - Valves | 131 gpm |
Full Flow - Valves | Yes |
Application - Valves | General Purpose |
Length | 6 1/8 in |
Cap to Inlet Center | 2 11/16 in |
Standards | ASTM B584 |
