Item - Check Valves: Check Valve; Flow Design: Single; Mechanism and Body Design: Inline Spring; Body Material - Valves: PVC; Pipe or Tube Size - Check Valves: 3 in; Connection Type - Check Valves: FNPT x FNPT; Cracking Pressure - Check Valves: 2 psi; Mounting Orientation - Check Valves: Horizontal, Vertical; Seal Material - Check Valves: EPDM; Max. Temp. - Valves: 140 Degrees F; Min. Temp. - Valves: 40 Degrees F; Max. Water Pressure - Valves: 150 psi @ 70 Degrees F; Max. Steam Pressure - Valves: Not Rated; Seat Material - Check Valves: PVC; Spring Material - Check Valves: Stainless Steel; Flow - Valves: 150 gpm; Application - Valves: General Purpose; Length: 10 5/16 in; Width: 5 1/2 in; Overall Height: 11 7/32 in; Cap to Inlet Center: 9 19/32 in; Hex Size: 3 1/2 in
| Item - Check Valves | Check Valve |
| Flow Design | Single |
| Mechanism and Body Design | Inline Spring |
| Body Material - Valves | PVC |
| Pipe or Tube Size - Check Valves | 3 in |
| Connection Type - Check Valves | FNPT x FNPT |
| Cracking Pressure - Check Valves | 2 psi |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Seal Material - Check Valves | EPDM |
| Max. Temp. - Valves | 140 Degrees F |
| Min. Temp. - Valves | 40 Degrees F |
| Max. Water Pressure - Valves | 150 psi @ 70 Degrees F |
| Max. Steam Pressure - Valves | Not Rated |
| Seat Material - Check Valves | PVC |
| Spring Material - Check Valves | Stainless Steel |
| Flow - Valves | 150 gpm |
| Application - Valves | General Purpose |
| Length | 10 5/16 in |
| Width | 5 1/2 in |
| Overall Height | 11 7/32 in |
| Cap to Inlet Center | 9 19/32 in |
| Hex Size | 3 1/2 in |
