Item - Check Valves: Check Valve; Flow Design: Single; Mechanism and Body Design: Y True Union; Body Material - Valves: PVC; Pipe or Tube Size - Check Valves: 2 1/2 in; Connection Type - Check Valves: FNPT x FNPT; Cracking Pressure - Check Valves: 1 psi; Mounting Orientation - Check Valves: Horizontal, Vertical; Seal Material - Check Valves: EPDM; Max. Temp. - Valves: 140 Degrees F; Min. Temp. - Valves: 40 Degrees F; Max. Water Pressure - Valves: 150 psi @ 70 Degrees F; Max. Steam Pressure - Valves: Not Rated; Seat Material - Check Valves: EPDM; Flow - Valves: 75 gpm; Full Flow - Valves: Yes; Application - Valves: General Purpose; Length: 16 49/64 in; Width: 6 13/32 in; Overall Height: 10 29/64 in; Cap to Inlet Center: 7 13/32 in; Hex Size: 3 1/2 in
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
