| Item | 50 Hz Motor |
| Motor Application | General Application |
| Motor Type | 3-Phase |
| Enclosure | Totally Enclosed Fan-Cooled |
| HP | 3 |
| Number of Speeds | 1 |
| Nameplate RPM | 2850 |
| Voltage | 220/380/440 |
| Hz | 50 |
| Phase | 3 |
| Full Load Amps | 8.4/4.8/4.2 |
| Frame | 182T |
| Mounting | Base |
| Thermal Protection | None |
| Insulation Class | F |
| Service Factor | 1.15 |
| Bearings | Ball |
| Rotation | CW/CCW |
| Ambient Temperature | 40 Degrees C |
| Shaft Dia. | 1-1/8" |
| Shaft Length | 2-3/4" |
| Length Less Shaft | 10-3/4" |
| Overall Length | 13-1/2" |
| RPM Range | 1801-3000 |
| UNSPSC | 26101612 |
