Washdown Motor; Motor Application: Washdown; Motor Design: 3-Phase; Motor Enclosure Design: Totally Enclosed Fan-Cooled; HP: 1 1/2; Nameplate RPM: 1750; Frame: 56C; NEMA Design: B; Motor Shaft Rotation: CW/CCW; Voltage: 230/460; Full Load Amps: 4.8/2.4; Phase: 3; Hz: 60/50; Motor Mounting Position: All Angle; Motor Mounting Type: Face; Motor Bearings: Ball; Motor Frame Material: Stainless Steel; Motor Thermal Protection: None; Motor Service Factor: 1.15; Max. Ambient Temp.: 40 Degrees C; Shaft Dia.: 5/8 in; Shaft Length: 1 7/8 in; Motor Shaft Design: Keyed; Body Dia.: 6 1/2 in; Length Less Shaft: 10 13/16 in; Overall Length: 12 11/16 in; Ins. Class: F; RPM Range: 1701-1800; Duty: Continuous; Shaft Material: 303 Stainless Steel; Conduit Box: 300 Annealed Stainless Steel; Endshields: 300 Series Stainless Steel; Motor Efficiency Group: NEMA Premium Efficient; Nominal Efficiency: 94.1 %; CC Number: CC003A; Application: Washguard; Standards: CE Approved, CSA (LR2025), UL (E49747); Voltage Compatibility: 208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460; Green Certification or Other Recognition: NEMA Premium(R) Rated
| Item | Washdown Motor |
| Motor Application | Washdown |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| HP | 1 1/2 |
| Nameplate RPM | 1750 |
| Frame | 56C |
| NEMA Design | B |
| Motor Shaft Rotation | CW/CCW |
| Voltage | 230/460 |
| Full Load Amps | 4.8/2.4 |
| Phase | 3 |
| Hz | 60/50 |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Face |
| Motor Bearings | Ball |
| Motor Frame Material | Stainless Steel |
| Motor Thermal Protection | None |
| Motor Service Factor | 1.15 |
| Max. Ambient Temp. | 40 Degrees C |
| Shaft Dia. | 5/8 in |
| Shaft Length | 1 7/8 in |
| Motor Shaft Design | Keyed |
| Body Dia. | 6 1/2 in |
| Length Less Shaft | 10 13/16 in |
| Overall Length | 12 11/16 in |
| Ins. Class | F |
| RPM Range | 1701-1800 |
| Duty | Continuous |
| Shaft Material | 303 Stainless Steel |
| Conduit Box | 300 Annealed Stainless Steel |
| Endshields | 300 Series Stainless Steel |
| Motor Efficiency Group | NEMA Premium Efficient |
| Nominal Efficiency | 94.1 % |
| CC Number | CC003A |
| Application | Washguard |
| Standards | CE Approved, CSA (LR2025), UL (E49747) |
| Voltage Compatibility | 208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230 |
