Close-Coupled Pump Motor; Motor Application: Pump; Motor Sub Application: Close-Coupled Pump; Motor Design: Capacitor-Start; Motor Enclosure Design: Open Dripproof; HP: 2; Nameplate RPM: 1750; Frame: 182JM; Motor Shaft Rotation: CW/CCW; Voltage: 115/230; Full Load Amps: 23/11.5; Phase: 1; Hz: 60; Motor Mounting Type: Face/Base; Motor Bearings: Ball; Motor Frame Material: Rolled Steel; Motor Thermal Protection: None; Motor Service Factor: 1.15; Max. Ambient Temp.: 40 Degrees C; Shaft Dia.: 7/8 in; Shaft Length: 4 1/4 in; Motor Shaft Design: JM Threaded; Length Less Shaft: 10 9/16 in; Overall Length: 14 13/16 in; Ins. Class: F; Duty: Continuous; Nominal Efficiency: 75.5 %; Motor Efficiency Group: Standard Efficient; Inverter Rated: No; Standards: CSA Certified (LR2025), UL Recognized (E49747); Voltage Compatibility: 115, 115/230, 120, 120/240, 230, 240
| Item | Close-Coupled Pump Motor |
| Motor Application | Pump |
| Motor Sub Application | Close-Coupled Pump |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Open Dripproof |
| HP | 2 |
| Nameplate RPM | 1750 |
| Frame | 182JM |
| Motor Shaft Rotation | CW/CCW |
| Voltage | 115/230 |
| Full Load Amps | 23/11.5 |
| Phase | 1 |
| Hz | 60 |
| Motor Mounting Type | Face/Base |
| Motor Bearings | Ball |
| Motor Frame Material | Rolled Steel |
| Motor Thermal Protection | None |
| Motor Service Factor | 1.15 |
| Max. Ambient Temp. | 40 Degrees C |
| Shaft Dia. | 7/8 in |
| Shaft Length | 4 1/4 in |
| Motor Shaft Design | JM Threaded |
| Length Less Shaft | 10 9/16 in |
| Overall Length | 14 13/16 in |
| Ins. Class | F |
| Duty | Continuous |
| Nominal Efficiency | 75.5 % |
| Motor Efficiency Group | Standard Efficient |
| Inverter Rated | No |
| Standards | CSA Certified (LR2025), UL Recognized (E49747) |
| Voltage Compatibility | 115, 115/230, 120, 120/240, 230, 240 |
