Metric Motor; Motor Application: General Application; Motor Design: 3-Phase; Motor Enclosure Design: Totally Enclosed Fan-Cooled; HP: 1/4; kW: 0.18; Nameplate RPM: 1700; Frame: 63; Voltage: 230/460; Hz: 60/50; Phase: 3; Full Load Amps: 1/0.5; Motor Mounting Type: Rigid Base; Motor Thermal Protection: None; Ins. Class: F; Motor Service Factor: 1.15; Motor Bearings: Ball; Motor Frame Material: Cast Aluminum; Max. Ambient Temp.: 40 Degrees C; Motor Shaft Rotation: CW/CCW; Shaft Dia.: 11 mm; Shaft Length: 23 mm; Motor Efficiency Group: Standard Efficient; Nominal Efficiency: 68 %; Duty: Continuous; Standards: CE Certified, CSA Certified, UL Recognized; Voltage Compatibility: 208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
| Item | Metric Motor |
| Motor Application | General Application |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| HP | 1/4 |
| kW | 0.18 |
| Nameplate RPM | 1700 |
| Frame | 63 |
| Voltage | 230/460 |
| Hz | 60/50 |
| Phase | 3 |
| Full Load Amps | 1/0.5 |
| Motor Mounting Type | Rigid Base |
| Motor Thermal Protection | None |
| Ins. Class | F |
| Motor Service Factor | 1.15 |
| Motor Bearings | Ball |
| Motor Frame Material | Cast Aluminum |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Shaft Rotation | CW/CCW |
| Shaft Dia. | 11 mm |
| Shaft Length | 23 mm |
| Motor Efficiency Group | Standard Efficient |
| Nominal Efficiency | 68 % |
| Duty | Continuous |
| Standards | CE Certified, CSA Certified, UL Recognized |
| Voltage Compatibility | 208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460 |
