Direct Drive Motor; Motor Design: 3-Phase; Phase: 3; HP: 5; No. of Speeds: 1; Voltage: 208-230/460; Motor Shaft Rotation: CW/CCW; Frame: 56HZ; Motor Enclosure Design: Open Dripproof; Motor Mounting Type: Rigid Base; Shaft Dia.: 7/8 in; Shaft Length: 2 1/4 in; Number of Shafts: 1; Motor Thermal Protection: Auto; Nameplate RPM: 3450; Motor Application: OEM Replacement; Motor Sub Application: Direct Drive Fan/Blower; Full Load Amps: 13.5-12.4/6.2; Hz: 60; Ins. Class: B; Max. Ambient Temp.: 40 Degrees C; Motor Service Factor: 1; Motor Bearings: Ball; Body Dia.: 6 1/2 in; Length Less Shaft: 11 3/16 in; Overall Length: 13 1/2 in; Stud Size: 10-32 UNF- 2A; Capacitor Required: No; Application: General Purpose; Standards: CSA Certified (LR2025), UL Recognized (E6312)
| Item | Direct Drive Motor |
| Motor Design | 3-Phase |
| Phase | 3 |
| HP | 5 |
| No. of Speeds | 1 |
| Voltage | 208-230/460 |
| Motor Shaft Rotation | CW/CCW |
| Frame | 56HZ |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Rigid Base |
| Shaft Dia. | 7/8 in |
| Shaft Length | 2 1/4 in |
| Number of Shafts | 1 |
| Motor Thermal Protection | Auto |
| Nameplate RPM | 3450 |
| Motor Application | OEM Replacement |
| Motor Sub Application | Direct Drive Fan/Blower |
| Full Load Amps | 13.5-12.4/6.2 |
| Hz | 60 |
| Ins. Class | B |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Service Factor | 1 |
| Motor Bearings | Ball |
| Body Dia. | 6 1/2 in |
| Length Less Shaft | 11 3/16 in |
| Overall Length | 13 1/2 in |
| Stud Size | 10-32 UNF- 2A |
| Capacitor Required | No |
| Application | General Purpose |
| Standards | CSA Certified (LR2025), UL Recognized (E6312) |
