Milwaukee Valve Check Valve, 3/8 in, Single, Y Swing, Bronze, FNPT x FNPT - 508 3/8"
filler
Availability : Usually Ships in 20 Business Days
Class 200, Max. pressure: 200 psi (steam); 400 psi WOG Max. temp.: 550F,Bronze Y-Pattern Swing Check Valves,Y-pattern design permits easy maintenance. Feature a bronze body and disc and metal-to-metal seating. Mount vertical or horizontal. For use in plumbing and heating applications.,Meet MSS SP-80 standards.
| Item - Check Valves | Check Valve |
| Flow Design | Single |
| Mechanism and Body Design | Y Swing |
| Body Material - Valves | Bronze |
| Pipe or Tube Size - Check Valves | 3/8 in |
| Connection Type - Check Valves | FNPT x FNPT |
| Cracking Pressure - Check Valves | 0.5 to 0.75 psi |
| Mounting Orientation - Check Valves | Horizontal |
| Seal Material - Check Valves | Chrome, Cobalt |
| Max. Temp. - Valves | 550 Degrees F |
| Min. Temp. - Valves | -20 Degrees F |
| Max. Water Pressure - Valves | 400 psi @ 150 Degrees F |
| Max. Steam Pressure - Valves | 200 psi WSP |
| Seat Material - Check Valves | Bronze |
| Flow - Valves | 6 gpm |
| Full Flow - Valves | Yes |
| Application - Valves | General Purpose |
| Length | 2 1/4 in |
| Overall Height | 1 5/8 in |
| Cap to Inlet Center | 1 5/8 in |
| Standards | MSS SP-80 |
