Nidec US Motors U10E3DCR 3-Phase C-Face Footless Motor, 10 HP, 3-Phase, 1200 RPM, 208-230, 460V, 256TC Frame

NidecSKU: C2095344
MPN : U10E3DCR
Weight : 15.0 lb
filler

Price:
$1,293.37 $1,577.28

Availability : Usually Ships in 3-5 Business Days
  • Features: 40 degree C ambient, No derate on HP for 50 Hz, Suitable for Wye-Delta start

Item: General Purpose AC Motor, Motor Type: 3-Phase, HP: 10, Nameplate RPM: 1200, Voltage: 208-230/460, Frame: 256TC, Enclosure: Totally Enclosed, Rotation: CW/CCW, Hz: 50, 60, Phase: 3, Speeds: 1, Service Factor: 1.25, Insulation Class: F, Mounting: Unimount, Bearings: Ball, Base: None, Shaft Type: Key, Shaft Number: 1, Shaft Length: 4.25", Shaft Dia.: 1.625", "C" Dim: 25.7, Thermal Protection: No, Cooling: Fan Cooled, Efficiency: 89.5.

ItemGeneral Purpose AC Motor
Motor Type3-Phase
HP10
Nameplate RPM1200
Voltage208-230/460
Frame256TC
EnclosureTotally Enclosed
RotationCW/CCW
Hz50, 60
Phase3
Speeds1
Service Factor1.25
Insulation ClassF
MountingUnimount
BearingsBall
BaseNone
Shaft TypeKey
Shaft Number1
Shaft Length4.25"
Shaft Dia.1.625"
"C" Dim25.7
Thermal ProtectionNo
CoolingFan Cooled
Efficiency89.5
