Nidec US Motors U20V1B Inverter Duty Motor, 20 HP, 3-Phase, 7200-3600 RPM, 230, 460V, 256T Frame

NidecSKU: C2093390
MPN : U20V1B
Weight : 15.0 lb

filler

Price:
$2,053.34 $2,504.07

Availability : Usually Ships in 3-5 Business Days
  • Features: 40 degree C ambient, Aluminum end shields, 10:1 speed range, variable torque, 1.0 SF with PWM

Item: Metric Three Phase Motor, Motor Type: 3-Phase, HP: 20, Nameplate RPM: 7200-3600, Voltage: 230/460, Frame: 256T, Enclosure: Totally Enclosed, Rotation: CW/CCW, Hz: 60, Phase: 3, Service Factor: 1.15, Insulation Class: F, Bearings: Ball, Base: Removable, Shaft Type: Key, Shaft Number: 1, Shaft Length: 4.25", Shaft Height: 6.25", Shaft Dia.: 1.625", "C" Dim: 25.6, Protection: Thermostat, Thermal Protection: Yes, Cooling: Fan Cooled, Efficiency: 90.2.

ItemMetric Three Phase Motor
Motor Type3-Phase
HP20
Nameplate RPM7200-3600
Voltage230/460
Frame256T
EnclosureTotally Enclosed
RotationCW/CCW
Hz60
Phase3
Service Factor1.15
Insulation ClassF
BearingsBall
BaseRemovable
Shaft TypeKey
Shaft Number1
Shaft Length4.25"
Shaft Height6.25"
Shaft Dia.1.625"
"C" Dim25.6
ProtectionThermostat
Thermal ProtectionYes
CoolingFan Cooled
Efficiency90.2
