Redhat 24V DC Brass Solenoid Valve, 1/4" Pipe Size - EF8344G370

RedhatSKU: C1935669
MPN : EF8344G370
Weight : 5.05 lb
filler

Price:
$1,056.71 $1,288.67

Availability : Usually Ships in 7-10 Business Days

This RED HAT solenoid valve minimizes temperature rise and power draw so that you can reduce wiring and operate this DC valve directly off of the computer control. Model is for use in an inherently safe system which will not ignite an explosive atmosphere.,Low power,Intrinsically safe

ItemSolenoid Valve
Solenoid Valve Product GroupSolenoid Valve
Valve Ways and Positions4-Way/2-Position
Media - ValvesAir, Inert Gases
Pipe Size - Valves1/4 in
Min. Operating Pressure Differential10 psi
Max. Operating Pressure Differential Air/Inert Gas150 psi
Max. Operating Pressure Differential Light OilNot Rated
Environmental Rating - ValvesExplosion Proof, Indoor, Outdoor
Voltage24V DC
Coefficient of Volume0.8
Body Material - ValvesBrass
Coil Insulation ClassF
Seal Material - ValvesNBR
Orifice Dia.1/4 in
NEMA Rating3, 3S, 4, 4X, 6, 6P, 7, 9
Max. Fluid Temp.140 Degrees F
Watts1.4 W
Coil EnclosureExplosionproof and Watertight
Electrical Connections1/2 in Conduit w/18 in Leads
Overall Length3 1/8 in
Overall Width4 3/4 in
Overall Height4 11/16 in
Center Line Pipe Center Size2 5/16 in
