Speakman S-1496-AF Sentinel Mark II Shower Valve combination with Cross Handle

SpeakmanSKU: C1966942
MPN : S-1496-AF
Weight : 9.4 lb


$230.69 $354.90

Availability : Usually Ships in 7-10 Business Days

Speakman S-1496-AF Sentinel Mark II Shower Valve combination with Cross Handle

Includes Showerhead
Item Exposed Shower
Features Rough Chrome Plated Cast Brass Body, Brass Lever Handle, Anti Scald Balanced Pressure Shower Valve, Adjustable Temperature Limit Stop Prevents Scalding
Flow Rate 2.0 gpm
Mounting Type Wall
Number of Holes 2
ADA Compliant Yes
Finish Rough Chrome Plated
Shower Head Type Wall Mounted
Height 24.25
Width 7.5
Depth 7-1/8"
Connection 1/2"-14 NPTF
Standards ASME A112.18.1/CSA B125.1, ASSE 1016, WaterSense Certified
Face Dia. 2-3/4"
Height (In.) 25-15/64
Material of Construction Brass
Handle Finish Polished Chrome
Width (In.) 3-21/64
Handle Type None
Depth (In.) 7-3/4
Connection Type Threaded Pipe
Face Dia. (In.) 2-3/4
Flow Rate (GPM) 2.0 GPM
Primary Material Metal
Ligature Resistant No
Type Wall Mounted
Max. Flow 2.5 GPM
Connection (In.) 1/2
Valve Design Pressure Balance
Replacement Cartridge Ceramic
Color/Finish Polished Chrome
Hose Length (In.) 0.0
Manufacturers Warranty Length 5 yr
Valve Type Ceramic
Diverter Tub Spout Length 0
Showerhead Type Wall Mounted
Showerhead Function Single
Includes Handle Yes
Includes Valve Yes
Trim Plate Shape Circle
Faucet Body Material Brass
Connection Size 1/2 NPT female
Includes Hot Temperature Limit Yes
Vandal Resistant Features Vandal Resistant
ADA Compliance Yes
Includes Trim Plate Yes
Showerhead Material Plastic
Includes Cartridge Yes
Handle Length 4 in
Fixed Showerhead Width 2 3/4 in
Includes Fixed Showerhead Yes
Trim Finish Chrome
Includes Handheld Showerhead No
Trim Plate Height 4 in
Shower Valve Type Antiscald Pressure Balancing
Showerhead Spray Pattern Jet
Includes Stem No
Series Sentinel Mark II
Includes Check Stop No
CEC Compliant Non CEC Compliant
Includes Drain Stopper No
Fixed Showerhead Flow Rate 2 gpm
Trim Plate Width 4 in
Trim Plate Depth 6 in
Fixed Showerhead Thickness 3 17/32 in
Face Shape Circle
Showerhead Shape Bulb
Material Brass
Length 7.0
Faucet Operation Manual
Color Chrome
Number of Handles 1
Massage Feature No
Shower Head Shape Round
Installation Type Wall Mounted
Collection Sentinel Mark II
Activation Type Rotate Handle
Number of Jets 50
Theme Commercial
Scald Guard Included Yes
Warranty 5 Year Limited
Drain Included No
Handle Placement Center of Valve
Diverter Included No
Shower Arm Included No
Shower Head Face Diameter 2.76
Shower Head Function Single Function
Faucet Handle Style Lever
Handles Included Yes
CEC Certified No
Temperature Limit Control Yes
Spout Reach (In.) 0.0
Number of Spray Patterns 1
Assembly Required No
Rough-in Valve Template Included Yes
Flow Type Aerated
Vandal Resistant Yes
Hose Included No
Escutcheon Included No
Valve Included Yes
Pause Control No
Self-Cleaning Nozzles Yes
Spout Length (In.) 0.0
Max Deck Thickness (In.) 0.0
Weight 4.02
Integral Stops No
For Use With Speakman Repair Part RPG03-0371-RCP Valve handle stem washer O-Ring, Speakman Repair Part RPG04-0367-PC Lever handle Mark II shower, Speakman Repair Part RPG05-0846 Mark II shower cartridge
Spout Height (In.) 0.0
Number of Showerheads 1
