Top Brand Check Valve, 3/8 in, Single, Inline Swing, 316 Stainless Steel, FNPT x FNPT - 4VMU9

Top BrandSKU: C1911176
MPN : 4VMU9
Weight : 1.0 lb

filler

Price:
$56.38 $90.94

Availability : Usually Ships in 3 Business Days

316 Stainless Steel Swing Check Valves, Max. pressure: 200 psi Max. temp.: 353F,Provide excellent corrosion and chemical resistance. Horizontal mounting. For use in plumbing and heating applications.

Item - Check ValvesCheck Valve
Flow DesignSingle
Mechanism and Body DesignInline Swing
Body Material - Valves316 Stainless Steel
Pipe or Tube Size - Check Valves3/8 in
Connection Type - Check ValvesFNPT x FNPT
Cracking Pressure - Check Valves0.5 psi
Mounting Orientation - Check ValvesHorizontal
Seal Material - Check ValvesPTFE
Max. Temp. - Valves350 Degrees F
Min. Temp. - Valves-4 Degrees F
Max. Water Pressure - Valves200 psi
Max. Steam Pressure - Valves200 psi WSP
Flow - Valves5.1 gpm
Full Flow - ValvesYes
Application - ValvesGeneral Purpose
Length2 9/16 in
Width1 53/64 in
Overall Height2 9/16 in
Cap to Inlet Center1 11/16 in
Hex Size1 1/16 in
