Features only 1 moving part to reduce maintenance. Disc has O-ring seal design for positive sealing. Short disc stroke helps reduce potential water hammer. Unrestricted full flow area and smooth streamlined contouring body allow for passage of large solids and minimizes the potential for clogging.
| Item - Check Valves | Check Valve |
| Flow Design | Single |
| Mechanism and Body Design | Inline Swing Flex |
| Body Material - Valves | Cast Iron |
| Pipe or Tube Size - Check Valves | 8 in |
| Connection Type - Check Valves | Flange x Flange |
| Cracking Pressure - Check Valves | 0.25 psi |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Seal Material - Check Valves | Metal |
| Max. Temp. - Valves | 200 Degrees F |
| Min. Temp. - Valves | 33 Degrees F |
| Max. Water Pressure - Valves | 250 psi |
| Max. Steam Pressure - Valves | Not Rated |
| Seat Material - Check Valves | Buna-N |
| Flow - Valves | 2,250 gpm |
| Full Flow - Valves | No |
| Application - Valves | General Purpose |
| Length | 19 1/2 in |
| Width | 13 1/2 in |
| Standards | ANSI B16.1 Class 125 |
