Bobrick B-6806x24 (24 x 1.5) Concealed Mounting W/ Snap Flange Grab Bars
Availability : In Stock - Usually Ships Same Business Day
✅ ADA Compliant Grab Bar For Commercial Restrooms
✅ 18” Straight Grab Bar With Concealed Snap Flange Mounting
✅ 18-Gauge Stainless Steel With Satin Finish
✅ 1-1/2” Diameter Bar With 1-1/2” Wall Clearance
✅ Concealed Mounting Hides Hardware For Clean Appearance
✅ Supports Up To 900 Lbs When Properly Installed
The Bobrick B-6806x24 Concealed Mounting With Snap Flange Grab Bar is included in the 6806 Series of washroom accessories available from Bobrick. The grab bar is made from durable, 18-gauge stainless steel and measures 24 inches in length by 1-1/2 inches in diameter. Since the grab bar will likely be handled often, the stainless steel has a satin finish, which makes fingerprints less noticeable. Concealing the installation hardware for the grab bar is a 22-gauge, 3-1/4-inch diameter stainless steel cover that snaps in place on the mounting flange. Measuring 1/8 inches in thickness, the mounting flange is welded to the grab bar, which passes through the flange to make one solid piece. The flange is 2 inches wide and 3-1/8 inches tall. If you install the Bobrick B-6806x24 Concealed Mounting With Snap Flange Grab Bar with 1-1/2 inches of clearance, the unit will support as much as 900 pounds of weight. 6806 Series, Stainless Steel, Stain Finish, Concealed Mounting with Snap Flange Grab Bars, 24", Straight
| Product Type | Grab Bar |
| Material | Stainless Steel |
| Nominal Size (In.) | 24" X 1.5" |
| Surface Type | Smooth |
| Length (In.) | 24" |
| Dia. (In.) | 1.5" |
| Total Recycled Content | 65% |
